Manual Rotation Stage, Aperture , 2.65 in. Diameter, 10° Fine, 6-32 and 1/4-20

  • Optic Diameter
    25.4 mm
  • Coarse Travel
    360°
  • Fine Travel
    10°
  • Diameter
    65 mm
  • Graduations
  • Load Capacity
    98 N
  • Thread Type
    6-32 and 1/4-20
  • Clear Aperture
    19.05 mm
  • Retaining Ring
    A-1.25-1RR
    (2 Included)
  • Retaining Ring Thread
    1.063-20
  • Vernier
    0.2°
  • Weight
    182 g
  • Included Actuators
    Actuator not included
  • Recommended Adjustment Screw
  • Recommended Vernier Micrometer
  • Recommended Lockable Micrometer
  • Recommended TRA Motorized Actuator
  • Recommended TRB Motorized Actuator
