Fiber-Optic Receiver, DC-Coupled, 800-1650 nm, 12 GHz, FC Multimode
The 1544-B-50 DC-Coupled NIR Fiber-Optic Receiver is ideal for applications that require high sensitivity, high speed, and clean responses. It offers clean responses and 32-ps rise times making it well-suited for time-domain characterization of 10-Gbit/s components. Its high gain and well-behaved frequency response also make it useful for frequency-domain measurements. For higher responsivity from 800-1650 nm, this photoreceiver has a 50 μm core multimode fiber input and consists of our new, improved InGaAs PIN photodiodes followed by a GaAs HBT amplifier.
An external power supply, which must be purchased separately, is required – we recommend our
