I-V Test Station, 10 Amp Max, Software and Meter Included

Technical Specs

  • Current Range
    -4A - +10A
  • Current Accuracy
    <0.23% across all ranges
  • Current Resolution
    10pA - 10µA
  • Voltage Range
    ±2.5 V
  • Voltage Accuracy
    ±0.02%
  • Voltage Resolution
    1µV - 1mV
  • Output Power
    25 W
  • Disk Space
    600 MB minimum required
  • Duration of IV Measurement
    0.6 - 58 sec w/ 0.5 sec pre-sweep delay
  • Number of Measurement Points
    2 - 1000
  • Communication Interface
    GPIB-USB
  • Thermistor Temperature Accuracy
    ±0.25°C @ 25°C
  • Operating System
    Windows XP™, Service pack 2 or 3; Windows 7 or 10, 32-bit or 64-bit
  • Electrical Interface
    4-wire probing, 4 quadrant sourcing and sinking
  • Software
    LabView 2009 SP1 GUI
  • Memory
    512 MB available RAM required
