CONEX-NSA12V6 Motorized Actuator

The CONEX-NSA12V6 miniature motorized linear actuators with 11 mm travel is vacuum compatible to 10^-6 Torr, and is an ideal solution for motorizing mirror mounts, rotation stages, linear stages, and other manual motion devices. It is ideal for remote adjustment of sensitive, hard-to-reach optical components in vacuum chambers. Typical applications include optimizing the alignment of a laser cavity, zeroing in on coherence lengths, or just adjusting the pointing of a beam over a long distance.

Due to the various feed-through configurations and preferences of customers, a wire color code is included. The controller supplied with the actuator is not vacuum compatible.

Power Supply, FC-PS40, to be ordered separately.

Cable Adapter, USB-RS422-1.8 to be ordered separately.

Specifications

Technical Specs

Stage Type

NSA12 Linear Actuator
Travel Range

11 mm
Push Force

14 N
Maximum Speed

0.45 mm/s
Minimum Incremental Motion

0.20 µm
Uni-directional Repeatability, Typical

±2.2 µm
Bi-directional Repeatability, Typical

±5.0 µm
Drive Type

Micro Step Drive Stepper
Drive Mechanism

Direct drive, non-rotating lead screw
Drive Screw Pitch

0.3048 mm
Limit Switches

Optical Home switch on the motor side, use software limit for maximum travel limitation
Origin

Optical, at lower limit

Origin Repeatability

±2 µm
Feedback

Open loop, no encoder
Weight

0.1 kg
Power Requirements

24 VDC, 8 W
Cable Length

3 m
Computer Interfaces

USB
Controller Dimensions

93.2 x 53 x 23 mm
Vacuum Compatibility

10^-6 Torr
MTBF

10,000 h ( 25% load, 10% duty cycle)
Compliance

RoHS 3, CE

Stage Type

NSA12 Linear Actuator
Travel Range

11 mm
Push Force

14 N
Maximum Speed

0.45 mm/s
Minimum Incremental Motion

0.20 µm
Uni-directional Repeatability, Typical

±2.2 µm
Bi-directional Repeatability, Typical

±5.0 µm
Drive Type

Micro Step Drive Stepper
Drive Mechanism

Direct drive, non-rotating lead screw
Drive Screw Pitch

0.3048 mm
Limit Switches

Optical Home switch on the motor side, use software limit for maximum travel limitation
Origin

Optical, at lower limit

Origin Repeatability

±2 µm
Feedback

Open loop, no encoder
Weight

0.1 kg
Power Requirements

24 VDC, 8 W
Cable Length

3 m
Computer Interfaces

USB
Controller Dimensions

93.2 x 53 x 23 mm
Vacuum Compatibility

10^-6 Torr
MTBF

10,000 h ( 25% load, 10% duty cycle)
Compliance

RoHS 3, CE
