Optical Filter, Shortpass, 25.4 mm, 800 nm Cut-off, 475-785 nm Transmission

The 10SWF-800-B Shortpass Edge Filter is a 1 in. (25.4 mm) diameter optical filter with a cut-off wavelength of 800 ±6 nm, and transmittance of 475-785 nm. Our short-wave pass filters have a steep transition between the region of transmission and reflection that is much steeper than colored glass filters. Shortpass filters have out-of-band rejection ≥OD 3 to 1200 nm. Typical transmission is ≥65% for short-wave pass filters. These optical filters are also available as part of the FS-SWF-B shortpass filter set.
