Four S-2000 clean-room vibration isolators 28 in. tall, automatic re-leveling

Model: S-2000AC-428

Four S-2000 clean-room vibration isolators 28 in. tall, automatic re-leveling

Model: S-2000AC-428

Technical Specs

  • Isolator Height
    28 in. (711.2 mm)
  • Load per Isolator
    2000 lb
  • Number of Isolators
    4
  • Tie Bar Flange
    No
  • Self Centering
    Yes
  • Settling Time
    1.5 s
  • Releveling Accuracy
    ±0.010 in.
  • Horizontal Damping
    Oil
  • Horizontal Isolation, 5 Hz
    85%
  • Horizontal Isolation, Resonance
    1.5 Hz
  • Horizontal Isolation, 10 Hz
    95%
  • Vertical Isolation, 10 Hz
    98%
  • Vertical Isolation, 5 Hz
    94%
  • Vertical Isolation, Resonance
    1 Hz
  • Height Adjustment
    +1.3 in.
  • Horizontal Amplification at Resonance
    9 dB
  • Vertical Amplification at Resonance
    10 dB
  • Maximum Air Pressure
    85 psi
  • Float Height Indicator
    Yes
  • Crated Weight
    270 lb
