Vertical Linear Stage, Precision Ball Bearing, 0.79 in. Travel, 10-24 & 1/4-20 Threads

Technical Specs

  • Travel Range
    20 mm
  • Load Capacity
    400 N
  • Thread Type
    10-24 and 1/4-20
  • Minimum Height
    110.0 mm
  • Maximum Height
    130 mm
  • Platform Size
    120 x 120 mm
  • Material
    Alloy Steel
  • Bearings
    Ball Bearing
  • Axes of Travel
    Z
  • Drive Location
    Center drive
  • Recommended Actuators
    BM25.40
  • Weight
    10 kg
  • Recommended BM Micrometer
