XY Cylindrical Device Mounts for X26 Rails

Products
Features
Contact Us

Overview

CT26 optical rail mounts are used to accurately position cylindrical lasers on the X26 rail system. These mounts are very useful for laboratory applications and remain highly rigid and stable for a long period of time.

Adjustable two-axis mounts for cylindrical lasers
0.16 in. (4 mm) XY travel
Compatible with X26 Series optical rails

See All Features

Products

Compare	Model	Compatibility	rankScore	Diameter	Availability	Price	Brand
CT26.35BM Cylindrical Laser Mount, 1.38 in. (35 mm), BM micrometers $1,381 4 Weeks	CT26.35BM Cylindrical Laser Mount, 1.38 in. (35 mm), BM micrometers	UNIVERSAL	1.0	35 mm	4 Weeks	$1,381	Newport
CT26.44BM Cylindrical Laser Mount, 1.73 in. (44 mm), BM micrometers $1,481 In Stock	CT26.44BM Cylindrical Laser Mount, 1.73 in. (44 mm), BM micrometers	UNIVERSAL	1.0	44 mm	In Stock	$1,481	Newport
CT26.50BM Cylindrical Laser Mount, 1.97 in. (50 mm), BM micrometers $1,688 Contact Us	CT26.50BM Cylindrical Laser Mount, 1.97 in. (50 mm), BM micrometers	UNIVERSAL	1.0	50 mm	Contact Us	$1,688	Newport

Show All

Features

Compatible with X26 Optical Rail System

Two mounts are recommended for holding each cylindrical device to enable 0.16 in. (4 mm) of stable XY and tip/tilt adjustment. The beam height is 40 mm, directly compatible with the X26 rail system with no carrier required. Lateral sensitivity is on the order of the BM actuator sensitivity.
