Optical Table, No Tuned Damping, 1200 x 1800 mm, 203 mm Thick, M6

The M-RPR-46-8 RPR Reliance™ Industrial and Educational Grade Optical Table features the material workmanship and quality found in all Newport tables and meets many general application needs. This 203 mm thick optical table has a 1200 mm width, a 1800 mm length, and Metric M6 holes on a 25 mm grid. The RPR offers the same broadband damping, static rigidity, and thermal stability capabilities as the RS Series but at a more modest price. The RPR Series offers Newport performance and quality at an affordable price for many less stringent applications.

Specifications

Technical Specs

Type
Optical Table Top
Optical Table Supports
Not Included
Broadband Damping
Constrained layer core, damped working surface and composite edge finish
Tuned Damping
No
Active Damping
No
Width
1200 mm
Length
1800 mm
Thickness
203 mm
Working Surface
4.8 mm thick 400 series ferromagnetic stainless steel
Surface Flatness
±0.1 mm over 600 mm square
Mounting Holes
M6

Mounting Hole Pattern
25 mm grid
Alpha-Numeric Grid Labels
Yes
Mounting Hole Borders
12.5 mm
Hole Sealing Type
Easy clean conical cup, 19 mm deep, non-corrosive high impact polymer material
Core Design
Trussed honeycomb, vertically bonded closed cell construction, 0.25 mm steel sheet materials, 0.76 mm triple core interface
Bottom Skin Material
4.8 mm thick carbon steel
Non-Magnetic Surface
No
Weight
278 kg
Crated Weight
350 kg

Type
Optical Table Top
Optical Table Supports
Not Included
Broadband Damping
Constrained layer core, damped working surface and composite edge finish
Tuned Damping
No
Active Damping
No
Width
1200 mm
Length
1800 mm
Thickness
203 mm
Working Surface
4.8 mm thick 400 series ferromagnetic stainless steel
Surface Flatness
±0.1 mm over 600 mm square
Mounting Holes
M6

Mounting Hole Pattern
25 mm grid
Alpha-Numeric Grid Labels
Yes
Mounting Hole Borders
12.5 mm
Hole Sealing Type
Easy clean conical cup, 19 mm deep, non-corrosive high impact polymer material
Core Design
Trussed honeycomb, vertically bonded closed cell construction, 0.25 mm steel sheet materials, 0.76 mm triple core interface
Bottom Skin Material
4.8 mm thick carbon steel
Non-Magnetic Surface
No
Weight
278 kg
Crated Weight
350 kg

Resources & Downloads

2D Product Drawings

Isolator Mounting Hole Dim MM(140.5 kB, PDF)
Leg Location And Mounting Dimensions(102.7 kB, PDF)

Manuals

Optical Table Pre-installation Checklist(3.7 MB, PDF)

Related Products

Accessories

Similar

	Compare	Description	Compatibility	Drawings, CAD & Specs	Avail.	Price
		M-RS2000-46-8Optical Table, 2 Tunable Dampers, 1200 x 1800 mm, 203 mm Thick, M6	METRIC
		M-ST-UT2-46-8Optical Table, Tuned-Damped, Upgradable, 1200 x 1800 mm, 203 mm Thick, M6	METRIC
		M-RS4000-46-8Optical Table, 6 Tunable Dampers, 1200 x 1800 mm, 203 mm Thick, M6	METRIC

Frequently Purchased Together

	Compare	Description	Compatibility	Drawings, CAD & Specs	Avail.	Price
		RL-2000-428Rigid Optical Table Leg Set, 28 in. Height, Qty 4, 8,000 lb. Load	UNIVERSAL			$2,490
