78253 Fiber Optic Cable

uv-vis large core fiber optic cable model 78253

Fiber Optic Cable, UV-VIS, 400 µm Core, 500 µm Clad, 1m Length, SMA

Model: 78253

$215

In Stock

Compare

Add to List

Product Series Overview

UV-NIR Large Core Fibers

The 78253 UV-VIS Single Fiber Cable has a core diameter of 400 μm supporting our and Bench-top Spectrometers. This version has 500 μm cladding, and is 1 meter long with SMA connectors. For coupling directly to an IS mini spectrometer, we recommend using no less than a 400 μm core fiber, particularly if working in the UV.

Specifications

Technical Specs

Type

UV-VIS Large Core Fiber
Core Diameter

400 µm
Cladding Diameter

500 µm
Numerical Aperture

0.22
Transmittance Range

250 - 1150 nm

Fiber Length

1 m
Fiber Connector

SMA
Cable Diameter

4.8 mm
Minimum Bend Radius

100 mm

Type

UV-VIS Large Core Fiber
Core Diameter

400 µm
Cladding Diameter

500 µm
Numerical Aperture

0.22
Transmittance Range

250 - 1150 nm

Fiber Length

1 m
Fiber Connector

SMA
Cable Diameter

4.8 mm
Minimum Bend Radius

100 mm
