F-UVE-65 UV-Curing Epoxy

UV-Curing Epoxy, 1 oz. (30ml), Flexible, Low Strain Applications

Model: F-UVE-65

$40

In Stock

Compare

Add to List

Product Series Overview

UV-curing Epoxy

The F-UVE-65 (NOA 65) UV-curing liquid polymer adhesive is suited for fast, high-precision bonding of optics. The transmission of a 0.25 mm thick adhesive layer is greater than 98% from 400–2000 nm.
The F-UVE-65 adhesive is flexible for low strain applications, and can be pre-cured in just seconds and fully-cured in minutes with a 350–380 nm, 100 mW UV mercury spot lamp. Available in 1 oz. (30 ml) applicator bottles.

Specifications

Technical Specs

Type

Epoxy
Operating Temperature

-15°C to 60°C
Glass Adhesion

Good
Metal Adhesion

Good
Plastic Adhesion

Fair

Recommended Use

Flexible; for low-strain applications or cold blocking of lenses
Refractive Index, Cured

1.52
Viscosity

1000 cps

Type

Epoxy
Operating Temperature

-15°C to 60°C
Glass Adhesion

Good
Metal Adhesion

Good
Plastic Adhesion

Fair

Recommended Use

Flexible; for low-strain applications or cold blocking of lenses
Refractive Index, Cured

1.52
Viscosity

1000 cps

Resources & Downloads

Other

F-UVE-65 RoHS Certificate (267.2 kB, PDF)
