Multimode Fiber, Graded Index, High Temp, 850/1300 nm, 0.29 NA, 100 µm Core

Technical Specs

  • Index Profile
    Graded
  • Fiber Type
    Multimode
  • Core Diameter
    100 ±4 µm
  • Cladding Diameter
    140 ±3 µm
  • Coating Diameter
    170 ±5 µm
  • Operating Wavelength
    850/1300 nm
  • Maximum Attenuation
    5.0/3.0 dB/km @850/1300 nm
  • Bandwidth
    100 MHz-km @850/1300 nm
  • Numerical Aperture
    0.29
  • Proof Test
    100 kpsi
