Glan-Thompson Linear Polarizer, 1.0 in. Rotatable Housing, 100,000:1, 400-700 nm

Rotatable Glan-Thompson Calcite Polarizers

The 5524 VIS Glan-Thompson Polarizer is built into a rotation stage, which easily mounts into standard 1.0 in. diameter mirror mounts or rotary stages. At the interface between two calcite prisms, total internal reflection takes place for one polarization state while the other is transmitted. This proven Glan-Thompson design yields extinction ratios greater than 100,000:1 over a wide range of angles and for a broad spectral range. The 5524 is AR coated for use from 400-700 nm.

Specifications

Technical Specs

Diameter
25.4 mm
Wavelength Range
400-700 nm
Material
Optical Grade Calcite
Extinction Ratio
100000:1
Damage Threshold
10 W/cm²

Clear Aperture
4.8 mm
Transmission
>95%

Diameter
25.4 mm
Wavelength Range
400-700 nm
Material
Optical Grade Calcite
Extinction Ratio
100000:1
Damage Threshold
10 W/cm²

Clear Aperture
4.8 mm
Transmission
>95%

Resources & Downloads

Other

502524-01 RoHS Certificate(264.2 kB, PDF)
502524-01_ROHS2-2021.pdf(280.7 kB, PDF)

2D Product Drawings

552xg-Drawing(88.4 kB, PDF)
