MVC Series Economy Microscope Objective Lenses

MVC Series Economy Microscope Objective Lenses

MVC Series Economy Microscope Objective Lenses

These economy objectives are ideal for collimating and focusing laser beams in the visible spectrum. These objectives are precision fabricated and assembled which make them an excellent choice for standard laboratory applications.

General purpose objective lens
Visible AR coated
Most economical option
Finite conjugate objectives

See All Features

	Compare	Description	Compatibility	Drawings, CAD & Specs	Magnification	Avail.	Price
		MVC-4XMicroscope Objective Lens, ValuMax, 4x, 0.1 NA, 400-700 nm	UNIVERSAL		4x	In Stock FREE 2-day shipping on thousands of products on Newport.com Learn More	$81
		MVC-10XMicroscope Objective Lens, ValuMax, 10x, 0.25 NA, 400-700 nm	UNIVERSAL		10x	In Stock FREE 2-day shipping on thousands of products on Newport.com Learn More	$92
		MVC-20XMicroscope Objective Lens, ValuMax, 20x, 0.4 NA, 400-700 nm	UNIVERSAL		20x	In Stock FREE 2-day shipping on thousands of products on Newport.com Learn More	$139
		MVC-40XMicroscope Objective Lens, ValuMax, 40x, 0.65 NA, 400-700 nm	UNIVERSAL		40x	In Stock FREE 2-day shipping on thousands of products on Newport.com Learn More	$146
		MVC-60XMicroscope Objective Lens, ValuMax, 60x, 0.85 NA, 400-700 nm	UNIVERSAL		60x	In Stock FREE 2-day shipping on thousands of products on Newport.com Learn More	$169

Specifications

Models
Magnification	4x	10x	20x	40x	60x
Numerical Aperture	0.1	0.25	0.4	0.65	0.85
Wavelength Range	400-700 nm	400-700 nm	400-700 nm	400-700 nm	400-700 nm
Effective Focal Length (EFL)	28.9 mm	15.3 mm	7.8 mm	4.2 mm	2.6 mm
Working Distance	15.1 mm	8.57 mm	8.72 mm	0.38 mm	0.48 mm
Tube Length	160 mm	160 mm	160 mm	160 mm	160 mm
Thread Type	0.800-36 RMS	0.800-36 RMS	0.800-36 RMS	0.800-36 RMS	0.800-36 RMS

Accessories

RMS Threaded Adapters and Mounts

	Compare	Description	Compatibility	Drawings, CAD & Specs	Avail.	Price
		LT10-RMS-NThread Adaptor, 1.0 in. Lens Tubes, 1.035-40 to 0.800-36 RMS Thread	UNIVERSAL		In Stock FREE 2-day shipping on thousands of products on Newport.com Learn More	$24
		UPA-OMObjective Lens Adapter, RMS Thread, 1 inch Mount	UNIVERSAL		In Stock FREE 2-day shipping on thousands of products on Newport.com Learn More	$50
		LPMH-05Objective Lens Holder, RMS, 0.875-20 Thread, For LP-05A Series	UNIVERSAL		3 Weeks FREE 2-day shipping on thousands of products on Newport.com Learn More	$38
		LPMH-1Objective Lens Holder, RMS, 1.438-20 Thread, For LP-1A Series	UNIVERSAL		In Stock FREE 2-day shipping on thousands of products on Newport.com Learn More	$37
		561-OBJObjective Lens Mount, 561 Series	UNIVERSAL		In Stock FREE 2-day shipping on thousands of products on Newport.com Learn More	$174
		LH-RMSMicroscope Objective Mount, Fixed, A-LINE, 0.800-36 Thread, 8-32	IMPERIAL		In Stock FREE 2-day shipping on thousands of products on Newport.com Learn More	$31
		OC1-RMSObjective Lens Mount, Insertable, RMS Thread, Optics Cage Plus	UNIVERSAL		In Stock FREE 2-day shipping on thousands of products on Newport.com Learn More	$29
