Specifications
Linewidth
Seed laser dependent
Frequency Jitter
Seed laser dependent
Power Stability
±1% (±2°C), typical, seed laser dependent
ASE
(at maximum power and center wavelength)
<-45 dB (0.01 mm OSA resolution)
Beam Pointing Stability
<50 µrad (±2°C)
Optical Output
Optically-isolated, fiber-coupled
Longitudinal Mode
Single
Transverse Mode
TEM00
Polarization
Vertical
Beam Divergence
<1.5 mrad, typical
Minimum Optical Input
10-20 mW
Maximum Optical Input
100 mW
User Interface
Controller front panel, RS232, USB
Power Supply Requirement
100-240 VAC (50-60 Hz),
power consumption <105 W
Operating Temperature
15-30°C (environment)
Storage Temperature
0-50°C (environment)
Humidity
Non-condensing (environment)
