Resonant Phase Modulator, 0.75-1.0 GHz, 500-900 nm, 8-32 and M4
The 4421-02 Resonant Phase Modulator is for 500 to 900 nm visible applications requiring resonant frequencies from 0.75 to 1.0 GHz. It consists of an electro-optic crystal in a resonant microwave cavity to ensure efficient phase modulation and low drive-voltage requirements. A tuning slug allows manual adjustment of the resonant frequency over a 100 MHz range. 8-32 and M4 mounting holes.
Specifications
- TypeResonant Phase Modulator
- Wavelength Range500-900 nm
- MaterialMgO:LiNbO3
- Operating Frequency0.75 - 1.0 GHz
- ApertureØ2 mm
- VSWR<1.5
- Maximum Input Power2 W/mm2 @ 532 nm
- Maximum RF Power4 W
- Maximum V16.5 - 33.5 V @ 532 nm
- RF ConnectorSMA
- Input Impedance50 Ω
- RF Bandwidth0.5% freq.
- Modulation Depth0.094 - 0.19 rad/V @ 532 nm
