Plane Ruled Reflection Grating, 25 mm, 800 nm, 13.9 Blaze, 600 Gr/mm

The 10RG600-800-1 is a plane ruled reflection grating, with dimensions of 25 x 25 x 6 mm, 600 grooves per mm, 13.9° nominal Blaze angle, first order Littrow nominal wavelength of 800 nm, and coated with an aluminum coating.


Designed for first order Littrow use, Richardson Gratings' plane ruled reflection gratings are blazed for specific wavelengths and generally have high efficiency at those wavelengths. Ruled gratings comprise the majority of diffraction gratings used in spectroscopic instrumentation and are especially useful in systems requiring high resolution.
