Specifications
Wavenumber Range
> 50 standard wavelengths, up to 10 wavelength channels per device
(Custom wavelengths and > 10 channels are available upon request.)
Spectral Range
340-900 nm
Spectral Resolution
10 nm @ λ ≤ 380 nm
8 nm @ λ > 380 nm
(Custom resolutions are available)
Stray Light
> OD 3
Linearity
> OD 3.5
Detector
Si photodiode linear array in 40-pin DIP
Responsivity
Nominal 0.43 A/W @ 633 nm
Photodiode Reverse Bias
-15 V maximum
Entrance Aperture
Nominal 4 mm diameter
Operating Temperature Range
-20° C to 60° C
Storage Temperature Range
-20° C to 80° C
Mounting
Standard DIP socket or direct PCB solder connection
Dimensions
51 x 16 x 25 mm (L x W x H)
Weight
Nominal 30 g
