S-2000AC Cleanroom Pneumatic Vibration Isolators

Specifications

Technical Specs

Load Capacity per Isolator
2000 lb (900 kg)
Type
Cleanroom Pneumatic Vibration Isolator
Tie Bar Flange
No
Float Height Indicator
Yes
Self Centering
Yes
Height Adjustment
+1.09/-0.25 in. (+27.7/-6.4 mm)
Horizontal Isolation, Resonance
1.5 Hz
Horizontal Amplification at Resonance
9 dB

Horizontal Isolation, 5 Hz
85%
Horizontal Isolation, 10 Hz
95%
Vertical Isolation, Resonance
1 Hz
Vertical Amplification at Resonance
10 dB
Vertical Isolation, 5 Hz
94%
Vertical Isolation, 10 Hz
98%

Load Capacity per Isolator
2000 lb (900 kg)
Type
Cleanroom Pneumatic Vibration Isolator
Tie Bar Flange
No
Float Height Indicator
Yes
Self Centering
Yes
Height Adjustment
+1.09/-0.25 in. (+27.7/-6.4 mm)
Horizontal Isolation, Resonance
1.5 Hz
Horizontal Amplification at Resonance
9 dB

Horizontal Isolation, 5 Hz
85%
Horizontal Isolation, 10 Hz
95%
Vertical Isolation, Resonance
1 Hz
Vertical Amplification at Resonance
10 dB
Vertical Isolation, 5 Hz
94%
Vertical Isolation, 10 Hz
98%
