Mirror Mount, Suprema®, Clear Edge, 1.0 in., (2) 100-TPI Locking Hex Actuators, Vacuum
Mirror Mount, Suprema®, Clear Edge, 1.0 in., (2) 100-TPI Locking Hex Actuators, Vacuum
Model: SN100C-F2H-V6
Product Series Overview
Low Outgassing and LaserClean Mirror MountsThe SN100C-F2H-V6 vacuum compatible Suprema® Stainless Steel Kinematic Optical Mounts are fabricated from powdered stainless steel and specially prepared for high vacuum environments. The SN100 Clear Edge version comes with removable 100-TPI actuators and has polished and lapped carbide pads which enable smooth, repeatable motion with outstanding stability. These mounts have a two-actuator configuration with locking Hex adjustment screws providing tip and tilt adjustability. Convenient 8-32 (M4) counterbored clearance holes provide quick, precise, secure and stable mounting. Suprema mounts are compatible with standard post and post holder systems for adjustable height and pedestal posts for a stable fixed height.
