Sorry, this product is no longer offered for sale. It was discontinued on Nov 22, 2021
Compact Air Mount, 9600 lb. Max. Load, 80 psi Max. Air Pressure
The SLM-96A Compact Air Mount without Self Leveling offers excellent support for high shock or applications requiring lower levels of vibration isolation. This mount supports 9600 lb maximum loads and has an 80 psi air pressure maximum. It can be used to isolate machinery from floor vibrations or the floor from machinery vibrations. The rigid wall design is far superior to conventional air bladders. SLM mounts also offer excellent protection against high static deflection, drift and permanent set. Once filled with air they are virtually maintenance free.
Specifications
- Load Capacity per Isolator9600 lb
- Minimum Isolator Load2400 lb
- Natural Frequency (Nominal), Max.5 Hz
- Natural Frequency (Nominal), Min.3 Hz
- Maximum Air Pressure80 psi
- Weight25.9 kg
Resources & Downloads
3D Product Models
Manuals
SLM Installation Instructions (SLM-1A & SLM-3A)(98.1 kB, PDF) SLM-6A to SLM-192A Air Mounts Installation Instructions(114.6 kB, PDF)
2D Product Drawings
06953 Dwg new-S(115.9 kB, PDF)
