Rotating Base, For M-SJ25.4, M3 & M6

Rotating Base, For M-SJ25.4, M3 & M6

Model: M-TSJ

$236

Show

Compare

Add to List

Product Series Overview

26 mm Optical Rail Mounts

The M-TSJ Metric Rotating Base allows coarse 360° positioning of the M-SJ25.4 kinematic mirror mount.

Specifications

Technical Specs

Type

Rotating Base
Mounting Threads

M3 & M6

Type

Rotating Base
Mounting Threads

M3 & M6

Resources & Downloads

2D / 3D CAD Software

Download CAD Files

Drawings And Cad

SJ25-4-S (119.1 kB, PDF)

Other

M-TSJ_RoHS2021.pdf (689.8 kB, PDF)
