Optical Post, 12.7 mm Height, 25.4 mm Diameter, M4 Thread
Optical Post, 12.7 mm Height, 25.4 mm Diameter, M4 Thread
Model: M-PS-0.5E
Product Series Overview
1.0 in. Optical PostsThe M-PS-0.5E Precision Ground Stainless Steel Optical Pedestal Extension is 25.4 mm diameter with a 12.7 mm height and M4 threads at each end. Optical pedestal extensions and spacers allow for many in between optical pedestal mounting heights. One mounting screw is included and pre-installed.
Resources & Downloads
Other
M-PS-0.5E RoHS Certificate(279.4 kB, PDF) M-PS-0-5E_RoHS2021.pdf(687.6 kB, PDF)
2D Product Drawings
PS-E Posts Drawing(186.7 kB, PDF)
