Laser Safety Glasses, Polycarbonate, 30% VLT, Argon, Diode, Dye, Excimer

The LV-F22.P1L02 is for Argon, Diode, Dye, Excimer, Nd:YAG (KTP + Harmonics) and Ti:Sapphire wavelengths. F22 style glasses with brown color polycarbonate lenses. Laservision's Polycarbonate eyewear is designed to provide excellent field-of-vision lenses with multiple wavelength coverage. 30 % VLT (visible light transmission). F22 glasses are light weight providing comfort during long term use, and easily fit over prescription eyewear. Meets ANSI Z136.1 and EN207 requirements.

Glasses Designed to Offer Complete Protection

The advanced filter technology implemented in these glasses ensures maximum visibility with unsurpassed attenuation at specific laser wavelengths. The transmission curve of each lens type is available for download here or on the individual product pages by clicking on a model number.

Optimal Field of View

Laservision's polycarbonate eyewear is designed to provide excellent field-of-vision lenses with multiple wavelength coverage.

Flexible Temples with Hinges and Light Weight for Comfort

These glasses features flexible temples with hinges. Coupled with their light weight, they provide comfort during long term use.

Fits Over Prescription Eyewear

The design of these goggles allows them to comfortably fit over prescription eyewear.

Specifications

Technical Specs

Frame Style
F22 OTG Glasses
Visible Light Transmission
30%
Filter Color
Brown
Filter Type
P1L02
Optical Density
OD > 8 @ 180-315 nm
OD > 8 @ 315-532 nm
OD > 7 @ 532-534 nm
OD > 6 @ 534-536 nm
OD > 5 @ 536-538 nm
OD > 4 @ 538-540 nm
OD > 3 @ 780-810 nm
OD > 4 @ 810-860 nm
OD > 5 @ 860-900 nm
OD > 5 @ 900-940 nm
OD > 7 @ 940-1070 nm
OD > 6 @ 1070-1080 nm
OD > 4 @ 1080-1100 nm
Laser Type
Argon
Diode
Dye
Excimer
Nd:YAG
Ti:Sapphire

Lens Material
Polycarbonate
CE
Yes
EN207
180 - 315 D LB8 + IR LB4 + M LB6
>315 - 532 D LB6+I LB7+RM LB8
>532 - 534 D LB6+IRM LB7
>534 - 536 DIRM LB6
>536 - 538 DIRM LB5
>538 - 540 DIRM LB4
780 - <810 DIRM LB3
810 - <860 DIRM LB4
860 - <900 DIRM LB5
900 - <940 DIRM LB6
940 - 1070 D LB6+IRM LB7
>1070 - 1080 DIRM LB6
>1080 - 1100 DIRM LB4
