Laser Diode Driver, Precision, 6A, 5V, USB, 220 VAC [Discontinued]
![Precision Laser Diode Drivers with USB [Discontinued]](https://api.p1.mks.com//medias/sys_master/DefaultCelumAssetsFolder/h4b/hf6/9901206962206/3525b_S-O_800w/3525b-S-O-800w.jpg)
The LDX-3565B Laser Diode Driver is a 6A microprocessor-based current source that offers a high stability, low noise output and integrated laser diode protection circuits. In addition to precision current control, the LDX-3565B Laser Diode Driver is loaded with standard features such as dual current ranges, constant power control, fine/coarse set point control, and external modulation capability. For automated testing applications in an R&D or production environment, remote operation is easily accomplished through the USB interface. For virtual instrument programming, LabVIEW® instrument drivers are available free of charge. LabVIEW® instrument drivers can be downloaded from the Literature and Downloads tab on this page.
We offer a wide variety of precision laser diode mounts with plug and play compatibility with our laser diode instrumentation.
Specifications
- Laser Current6 A
- Laser Drive Requirement1 to 10 A
- Laser Compliance Voltage5 V
- Temperature Coefficient<100 ppm FS/°C
- Computer InterfacesUSB
- Power Requirements220 VAC
- Laser Current Resolution500µA (2A Range)
1500µA (6A Range) - Laser Current Accuracy±0.15% of FS
- Laser Output Noise/Ripple Low Bandwidth30 µA
- Laser Output Noise/Ripple High Bandwidth100 µA
- Transfer Function600 mA/V
- Current Output 24 h Stability<50 ppm FS
- Current Output 1 h Stability<20 ppm FS
- External Modulation High BandwidthDC to 50 kHz
- External Modulation Low BandwidthDC to 0.08 kHz
- Photodiode Current Accuracy±0.1% of FS
- Photodiode Current Range0.01-25 mA
- Photodiode Reverse Bias0-5 V
- Connector TypeDB9 Female
- Display Type4-digit Green LED
Resources & Downloads
Application Notes
Protecting Your Laser Diode(2.3 MB, PDF) Laser Diode Characteristics Overview(392.5 kB, PDF)
Technical Notes
Output Current Accuracy of an LDX-3525B(315.7 kB, PDF) Long-Term Output Stability of an LDX-3525B(264.4 kB, PDF) Square Wave Modulation of the LDX-3500B(465.5 kB, PDF) Clamping Limit of an LDX-3525B(344.6 kB, PDF)
Software
ILX Lightwave USB Drivers(61.9 MB, ZIP) LDX-3500B LabVIEW Driver(343.1 kB, ZIP)
Manuals
LDX-3500B Laser Diode Drivers User's Manual(2.4 MB, PDF)
Literature
LDX-3500B Laser Diode Driver Brochure(802.4 kB, PDF) Pinout Diagrams for CC-305S and CC-505S Cables(88.5 kB, PDF)
