ISO-FRDY-02-532-W Faraday Optical Isolator

Faraday Optical Isolator, Compact, 2 mm, 532 nm, PM Isolator, 1/2 Waveplate, [DISCONTINUED]

Model: ISO-FRDY-02-532-W

$1,450

In Stock

Compare

Add to List

Product Series Overview

Compact Faraday Optical Isolators

The ISO-FRDY-02-532-W Compact Optical Isolator is essentially a uni-directional light valve. It is primarily used for elimination of frequency instability in single frequency lasers such as laser diodes and OPSLs, the prevention of mode-hopping in external cavity diode lasers, and the elimination of parasitic oscillations due to ASE in amplified laser systems. The compact design makes it highly suitable for OEM integration. It has a 2 mm clear aperture and a 522 nm to 542 nm wavelength range. The ISO-FRDY-02-532-W contains optically-contacted polarizing beam splitter cubes resulting in high transmission as compared to other available isolators. This -W version has an added 1/2 wave plate at the output stage.

Specifications

Technical Specs

Center Wavelength

532 nm
Spectral Range

522-542 nm
Clear Aperture

2 mm
Isolation

>33 dB
Transmission

>95%

Forward Power Handling

5W
Operating Temperature

10-30°C
Isolator Diameter

12 mm

Center Wavelength

532 nm
Spectral Range

522-542 nm
Clear Aperture

2 mm
Isolation

>33 dB
Transmission

>95%

Forward Power Handling

5W
Operating Temperature

10-30°C
Isolator Diameter

12 mm
