Gate Valve, DN100 Bore, Stainless Steel, Manual Actuation
The GVRAD080SSPVNN0000, a stainless-steel Gate Valve with a DN80 bore, Viton/FKM seals, and pneumatic actuation, is heatable to 105°C. It is optimized for isolation of roughing pumps and roughing lines in both semiconductor and general vacuum applications.
Specifications
Type
Gate Valve
Flange Size
DN100
Vacuum Range
1 x 10-7 to 1200 Torr
Valve Actuation
Manual
Body Material
Stainless Steel
Seal Material
Viton/FKM
Limit Switch
No
Operating Temperature Range
10 - 80°C
Maximum Bakeout Temperature
105°C
Maximum Differential Pressure Across Valve
1200 Torr (1.6 bar) chamber side high <22.5 Torr (30 mbar) pump side high.
