F-UVE-63 UV-Curing Epoxy

UV-Curing Epoxy, 1 oz. (30ml), Cures Thick, 350-2000nm

Model: F-UVE-63

$40

Compare

Add to List

Product Series Overview

UV-curing Epoxy

The F-UVE-63 (NOA 63) UV-curing liquid polymer adhesive is suited for fast, high-precision bonding of optics. The transmission of a 0.25 mm thick adhesive layer is greater than 98% from 400–2000 nm.
The F-UVE-63 adhesive cures thick, and can be pre-cured in just seconds and fully-cured in minutes with a 350–380 nm, 100 mW UV mercury spot lamp. Available in 1 oz. (30 ml) applicator bottles.

Specifications

Technical Specs

Type

Epoxy
Operating Temperature

-15°C to 60°C
Glass Adhesion

Good
Metal Adhesion

Good
Plastic Adhesion

Fair

Recommended Use

Cures well in thick sections; transmits 350–2000 nm
Refractive Index, Cured

1.56
Viscosity

2500 cps

Type

Epoxy
Operating Temperature

-15°C to 60°C
Glass Adhesion

Good
Metal Adhesion

Good
Plastic Adhesion

Fair

Recommended Use

Cures well in thick sections; transmits 350–2000 nm
Refractive Index, Cured

1.56
Viscosity

2500 cps

Resources & Downloads

Other

F-UVE-63 RoHS Certificate (265.7 kB, PDF)
