The 60D04ER.2 Broadband Metallic Mirror is an excellent general purpose, broadband reflectors. This 6 inch (152.4 mm) diameter mirror is made from a 23.5 mm thick Pyrex® substrate. Borofloat® 33 has low thermal expansion and is an excellent substrate for most applications. Our ER.2 protected silver coating is composed of a low emissivity silver film fully encapsulated by a multilayer dielectric stack to prevent oxidation. This coating has excellent broadband reflectivity in the IR, while maintaining very good performance in the visible and near IR. Average reflectivity is greater than 96% from 480–1100 nm and greater than 98.5% from 1.1–20 µm. This mirror has a λ/2 surface flatness and a 40-20 surface quality.
625-RC6-MMirror Mount, 38.1 mm Post Mounted, 152.4 mm Diameter, Micrometer
UNIVERSAL
In Stock
$725
60D04ER.2 - Drawings & CAD
Additional CAD file downloads are not available for this product.
60D04ER.2 - Drawings
Additional drawings are not available for this product.
60D04ER.2
Sign In
Request Resource
In order to provide better service and products, please provide the following brief information.
Password Reset
Enter your email address below to reset your account password.
Password Reset
Email Verification Required
Cart Items Updated
Remove Product
Remove this product from your comparison list?
Check Order Status
Provide an order number and postal code to check the status of an order or download an invoice for an order that has shipped. Login to view your complete order history.
Sign In Required
To access this and other valuable technical resources, please sign in or register for a new online account.
Add to Cart
Broadband Metallic Mirror, Pyrex, 152.4 mm, λ/2, 480-20,000 nm
