Compare Model Drawings, CAD & Specs Mounting Hole Type Width Length Thickness Working Surface Height Availability Price
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 3 x 6 ft., 6 in., 1/4-20
$4,401
1/4-20 3 ft. 6 ft. 6 in. 34.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 3 x 6 ft., 8 in., 1/4-20
$4,539
1/4-20 3 ft. 6 ft. 8 in. 36.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid,, 3 x 8 ft., 6 in., 1/4-20
$5,024
1/4-20 3 ft. 8 ft. 6 in. 34.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 3 x 8 ft., 8 in., 1/4-20
$5,221
1/4-20 3 ft. 8 ft. 8 in. 36.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 4 x 6 ft., 6 in., 1/4-20
$4,772
1/4-20 4 ft. 6 ft. 6 in. 34.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 4 x 6 ft., 8 in., 1/4-20
$4,882
1/4-20 4 ft. 6 ft. 8 in. 36.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 4 x 6 ft., 12 in., 1/4-20
$5,195
1/4-20 4 ft. 6 ft. 12 in. 40.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 4 x 7 ft., 6 in., 1/4-20
$5,102
1/4-20 4 ft. 7 ft. 6 in. 34.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 4 x 7 ft., 8 in., 1/4-20
$5,230
1/4-20 4 ft. 7 ft. 8 in. 36.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 4 x 7 ft., 12 in., 1/4-20
$5,710
1/4-20 4 ft. 7 ft. 12 in. 40.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 4 x 8 ft., 6 in., 1/4-20
$5,466
1/4-20 4 ft. 8 ft. 6 in. 34.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 4 x 8 ft., 8 in., 1/4-20
$5,620
1/4-20 4 ft. 8 ft. 8 in. 36.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 4 x 8 ft., 12 in., 1/4-20
$6,172
1/4-20 4 ft. 8 ft. 12 in. 40.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 4 x 9 ft., 6 in., 1/4-20
$5,732
1/4-20 4 ft. 9 ft. 6 in. 34.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 4 x 9 ft., 8 in, 1/4-20
$6,066
1/4-20 4 ft. 9 ft. 8 in. 36.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 4 x 9 ft., 12 in., 1/4-20
$6,327
1/4-20 4 ft. 9 ft. 12 in. 40.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 4 x 10 ft., 6 in., 1/4-20
$6,477
1/4-20 4 ft. 10 ft. 6 in. 34.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 4 x 10 ft., 8 in., 1/4-20
$6,631
1/4-20 4 ft. 10 ft. 8 in. 36.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 4 x 10 ft., 12 in, 1/4-20
$7,244
1/4-20 4 ft. 10 ft. 12 in. 40.7 ±0.5 in.
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 900 x 1800 x 152 mm, M6
$4,401
M6 900 mm 1800 mm 152 mm 881 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 900 x 1800 x 203 mm, M6
$4,539
M6 900 mm 1800 mm 203 mm 932 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 900 x 2400 x 152 mm, M6
$5,024
M6 900 mm 2400 mm 152 mm 881 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 900 x 2400 x 203 mm, M6
$5,221
M6 900 mm 2400 mm 203 mm 932 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 1200 x 1800 x 152 mm, M6
$4,772
In Stock
M6 1200 mm 1800 mm 152 mm 881 ±12.5 mm
In Stock
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 1200 x 1800 x 203 mm, M6
$4,882
M6 1200 mm 1800 mm 203 mm 932 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 1200 x 1800 x 305 mm, M6
$5,195
M6 1200 mm 1800 mm 305 mm 1034 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 1200 x 2100 x 152 mm, M6
$5,102
M6 1200 mm 2100 mm 152 mm 881 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 1200 x 2100 x 203 mm, M6
$5,230
M6 1200 mm 2100 mm 203 mm 932 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 1200 x 2100 x 305 mm, M6
$5,710
M6 1200 mm 2100 mm 305 mm 1034 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 1200 x 2400 x 152 mm, M6
$5,466
M6 1200 mm 2400 mm 152 mm 881 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 1200 x 2400 x 203 mm, M6
$5,620
M6 1200 mm 2400 mm 203 mm 932 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 1200 x 2400 x 305 mm, M6
$6,172
M6 1200 mm 2400 mm 305 mm 1034 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 1200 x 2700 x 152 mm, M6
$5,732
M6 1200 mm 2700 mm 152 mm 881 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 1200 x 2700 x 203 mm, M6
$6,066
M6 1200 mm 2700 mm 203 mm 932 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 1200 x 2700 x 305 mm, M6
$6,327
M6 1200 mm 2700 mm 305 mm 1034 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 1200 x 3000 x 153 mm, M6
$6,477
M6 1200 mm 3000 mm 152 mm 881 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 1200 x 3000 x 203 mm, M6
$6,631
M6 1200 mm 3000 mm 203 mm 932 ±12.5 mm
integrity series optical table system
Vibration Control System, Integrity 1, Rigid, 1200 x 3000 x 305 mm, M6
$7,244
M6 1200 mm 3000 mm 305 mm 1034 ±12.5 mm

For Integrity 1 VCS table system with pre-installed pneumatic isolators, click here

Specifications

  • Type
    Integrity 1 VCS Optical Table System
  • Tuned Damping
    No
  • Active Damping
    No
  • Broadband Damping
    Constrained layer core, damped working surface and composite edge finish
  • Optical Table Supports
    Rigid Support Legs (Upgradable to Isolators)
  • Working Surface Height
    34.7 ±0.5 in. (6 in. Thick Tables)
    36.7 ±0.5 in. (8 in. Thick Tables)
    40.7 ±0.5 in. (12 in. Thick Tables)
  • Working Surface
    3.4 mm thick ferromagnetic 430 stainless steel
  • Surface Flatness
    ± 0.006 in. (0.15 mm) over 2 ft. (600 mm) square
  • Mounting Hole Type
    1/4-20
    M6 (M- Versions)
  • Mounting Hole Pattern
    1.0 in. grid
    25 mm grid (M- Versions)
  • Mounting Hole Borders
    0.5 in.
    12.5 mm (M- Versions)
  • Alphanumeric Grid Labels
    No
  • Hole Sealing Type
    Easy clean conical cup, 0.75 in. (19 mm) deep, non-corrosive high impact polymer material
  • Core Design
    Trussed honeycomb, vertically bonded closed cell construction, 0.010 in. steel sheet materials, 0.030 in. triple core interface
  • Bottom Skin Material
    3.4 mm thick carbon steel
