902B Absolute Piezo Vacuum Pressure Transducers

Products
Accessories
Contact Us

Overview

The 902B Piezo transducer combines the pressure measurement technology of a MEMS-based Piezo sensor with a metal sealed stainless steel 316 diaphragm and integrated electronics. The 902B provides economical, absolute pressure measurement that is independent of gas type.

Please see 902B Absolute Piezo Transducers on mks.com for additional configurations.

Low cost transducer with 0.1 to 1000 Torr measurement range
Solid state Piezo sensor resistant to damage from air inrush and vibrations
Robust design and stainless steel construction for harsh processes
Gas independent accurate pressure measurement
Compact system design with integrated electronics and sensor in one unit

Products

		Compare	Model	Compatibility	sortOrder	rankScore	ranking	Drawings, CAD & Specs		Availability	Featured Item	Price		Brand
		902B-11030 Piezo Vacuum Transducer, 0.1-1000 Torr, NW16 ISO-KF, RS232, 0-10 VDC, DB15, 3 Relays $435 Contact Us	902B-11030 Piezo Vacuum Transducer, 0.1-1000 Torr, NW16 ISO-KF, RS232, 0-10 VDC, DB15, 3 Relays	UNIVERSAL	0.0	1.0	0.0		0.0	Contact Us		$435		MKS Instruments
		902B-11034 Piezo Vacuum Transducer, Display, 0.1-1000 Torr, NW16 ISO-KF, RS232, 0-10 VDC, DB15, 3 Relays $740 Contact Us	902B-11034 Piezo Vacuum Transducer, Display, 0.1-1000 Torr, NW16 ISO-KF, RS232, 0-10 VDC, DB15, 3 Relays	UNIVERSAL	0.0	1.0	0.0		0.0	Contact Us		$740		MKS Instruments
