750C Baratron® 20 to 3000 PSIA Absolute Capacitance Manometers

740C/750c baratron 20-3000 psia capacitance manometer

Overview

The 750C Baratron® Manometer is a rugged, industrial-grade absolute pressure transducer, offering superior accuracy, repeatability, and long-term signal stability. All exposed sensor surfaces have exceptional resistance to corrosion from a wide variety of aggressive chemicals. The sensor is fully welded, for protection during accidental exposure to dangerous chemicals.

Please see 750C Capacitance Manometers on mks.com for additional configurations.

20 to 3000 psia full scale ranges with ±1% of reading accuracy
4-20 mA, 0-5 VDC or 0-10 VDC output proportional to absolute pressure
Overpressure limit of two times Full Scale or 45 psia with no performance degradation
All-welded Inconel® sensor construction for use with corrosive media
Wide variety of fittings and electrical connectors for maximum flexibility

Specifications

Type

Pressure Transducer
Measurement Type

Absolute
Accuracy

1.0% of Reading
Operating Temperature Range

Range 0 - 50°C

Volume

4.9 cc
Exposed Materials

Inconel and 316L stainless steel
CE Certified

Yes

Specifications

Type

Pressure Transducer
Measurement Type

Absolute
Accuracy

1.0% of Reading
Operating Temperature Range

Range 0 - 50°C

Volume

4.9 cc
Exposed Materials

Inconel and 316L stainless steel
CE Certified

Yes
